• Sizes: 1/2″ – 12″
  • Class Ratings: 150 – 600
  • End Connections: RF, FF, SW, BW, RTJ
  • 1 Piece, 2 Piece and 3 Piece Body available
  • Full Bore and Reduced Bore options
  • Special sizes and ratings available on request

Floating Ball Valve

Floating Ball Valves are available from EDMUND VALVE COMPANY. Edmund Valve Company are specialists in manufacturing quality floating ball valves. Available in sizes from 1/2″ – 12″ and class ratings 150 through 600. Our floating ball valves can be made in Raised Face (RF) and Ring Type Joint (RTJ) to specification ANSI B16.5 and Butt Weld (BW) to specification ANSI B16.25. Other end connections are available on request.

Edmund Valve Company Floating Ball Valves are manufactured according to API 6D / BS5351. Our range is tested vigorously to API 598 and design standard ANSI B16.34. All of our products are supplied with EN10204 3.1 Test Certification. Further testing is available on customer request such as; radiography testing and Non-destructive Testing (NDT).

Manufactured in forged and Cast materials as well as machined from bar for the end of project requirements, so we can deliver in the shortest time possible.  3-piece; 2-piece & 1-piece flanged and screwed type are our key range, thereafter special design are assessed and made on a project by project basis.

We are able to customise our floating ball valves with actuation (pneumatic, hydraulic and electric).

Common Construction Materials

  • A105
  • A216 WCB / WCC
  • A350 LF2
  • A352 LCC / LCB
  • 316/304 Stainless Steel

Exotic Materials

We also offer Floating Ball Valves in a large selection of exotic materials including; Chrome Moly Alloy,  Duplex, Aluminium Bronze, Monel, Inconel and Titanium.
To find out more about our selection of materials visit our Exotic Materials page here.
